Electric Stacker Lifter 1T Lift Height 3000mm

ELECTRIC STACKER LIFTER 1T LIFT HEIGHT 3000MM

Note: This unit legs will not get inside closed pallets (will not go over the timber under pallet)

Introduction:

Warehouses differ on the type of product they produce, environment and demands. They hold significant jobs to deliver the consumer a quality product but for most them don’t have a huge space to operate. One good way to deal with this scenario is having the right equipment to use. A stacker jack is often used for one or more pallet to easily moved even in tight spaces.



Main Features:

This electric stacker is one of the best electric lifter produce by JIALIFT. It saves immensely on power consumption. We are highly appreciated by our clients for its reliability and safe operation. User friendly controls and saves more of your time. Lifting and moving pallets, even in tight spaces made possible by the help of this top-notch stacker lifter.



Brief Dimension:

• Load Capacity: 1000kg
• Load Capacity on Max Height: 700kg
• Max Lifting Height: 3000mm
• Load Center Distance: 600mm
• Service Weight: 465kg
• Fork Length: 1150mm
• Single Fork Width: 160mm
• Overall Fork Width: 570/695mm
• Lowered Fork Height: 86mm
• Fixed Leg Length: 928mm
• Single Fixed Leg Width: 124mm
• Inside width between fixed legs: 262/387mm
• Outside width between fixed legs: 534/659mm
• Turning Radius: 1336mm
• Aisle Width for Pallets 1000x1200 crossways: 2074mm
• Aisle Width for Pallets 800x1200 lengthways: 2040mm
• Overalls Length: 1755mm
• Overall Width: 795mm
• Extended Mast Height: 3432mm
• Lowered Mast Height:  1994mm
• Front Wheel Size, number: 80x70,4
• Rear Wheel Size, number: 210x70,1
• Balance Wheel Size, number: 150x58,1
• Driving Speed, laden/unladen: 4km/4.2h
• Lifting Speed, laden/unladen: 100mm/150s
• Lowering Speed, laden/unladen: 150mm/130s
• Drive Motor Rating: 0.75kW
• Lift Motor Rating: 2.2kW
• Controller: 24V/90A
• Charger: 24V/10A
• Battery Voltage/nominal capacity: 2x12V/100AH
• Battery Dimensions: 260/169/215mm





Warranty:

1 Year
